| Marke | NEUTRIK® |
| Anwendung | Video UHD |
| Farbe | schwarz |
| Ausführung | BNC |
| Bauform | gerade |
| Geschlecht | männlich |
| Material | Metall |
| Codierung | keine |
| Codierbar | Ja |
| Polzahl | 2-pol |
| Stecker/Buchse | Stecker |
| Kontaktart | Crimp |
| Kontakt-Beschichtung | hartvergoldet |
| Montageart | Kabel |
| Zugehörigkeit | Crimpeinsatz DIE-R-BNC-PDC |
| Kabeldurchmesser min. [mm] | 6,3 |
| Kabeldurchmesser min. ["] | 0.248 |
| Kabeldurchmesser max. [mm] | 6,3 |
| Kabeldurchmesser max. ["] | 0.248 |
| Übertragungsstandard | HD-SDI |
| Crimpmaß Pin [mm] | 1,600 |
| Crimpmaß Pin ["] | 0.063 |
| Crimpmaß Schirm [mm] | 6,470 |
| Crimpmaß Schirm ["] | 0.255 |
| Wellenwiderstand [Ω] | 75 |
Keine Maßangaben verfügbar.
