SMP-S4H – SierraView™ SM 4 x HDMI in 2 out MultiViewer 1RU

The SMP−xx is a fully−featured modular multi−format MultiViewer. Its flexibility lets you monitor a wide range of both video and audio sources on one or two independent displays at up to 4K@30Hz output resolutions.

• Multi–Format Video Input Cards — HDMI (with HDCP support), 3G HD–SDI, Composite Video, RGBHV (525/625 Lines Video level).
• 6 Input Slots — 4 for Audio/Video input, and 1 each for network and controller cards
• Frame Options — Standard SMP–Sxx or optional SMP–Rxx which includes a 16x16 3G HD–SDI router.
• Max Input Resolution — 1080p, 1920x1200 & 3G HD–SDI (SMPTE 424M).
• Free–Form Scale & Position — All video tiles are fully customizable.
• Multiple output card options — Offering DVI–D/HDMI and HD–SDI in parallel for each independent output.
• Embedded Audio Metering — Up to 16 channels of embedded audio per input.
• Audio Monitoring — Embedded audio on MultiView outputs and/or via Front Panel 1/4 Inch Jack.
• Hot Swappable Cards.
• Control & Setup Via LAN.
• Multiple Alarms, Clocks, Timers & Logos.
• Decoding & Monitoring — Closed caption and Teletext data.
• Under Monitor Display, GPI & Tally Support.
• Exceptional Image Quality — State of the art image processing algorithms.
• Multiple MultiViewers — 2nd output card can be added to give independent 4x2 and 8x2 MultiViewers in the same SMP–xx frame.
• Future Expansion — Up to 16 Inputs in the SMP–xx frame or up to 72 inputs via MP–xx frame.
• Genlock Input.
• Options — Redundant Power Supply (RPS), Analog & Digital Audio I/O cards for onscreen metering of external audio & VIP–3D Scaler Card for Dolby® E Metering (But not decoding).
• Size — 19" (1U).
• 5 Year Warranty.
